Description
- Advanced, comfort-focused suspension
- Powerful 999cc 2-cylinder Engine
- Three drive modes, one ultra-versatile machine
- Tyres designed for the toughest terrain
- On Command system - Turf Mode
- Advanced, comfort-focused suspension
- Spacious four-person cabin
- Four seats plus cargo
- Imposing and aggressive styling
- Rugged front bumper
- Stylish and helpful interior lighting
- Durability you can count on
REIMAGINE EVERYTHING.
Share your adventures in the comfortable, class-leading, auto-inspired cabin with four-seat versatility. The unmatched power of Yamaha's 999cc parallel-twin engine partners RMAX's unique D-Mode feature with Sport, Trail, and Crawl Modes, FOX® 2.0 iQS in-cabin adjustable shocks increase rider comfort, for off road exploring in style. #DRIVENBYFREEDOM
The Wolverine® RMAX™4 1000 Compact LE offers unprecedented style and comfort, but also expands your horizons, enabling you to take friends and family out for an exhilarating day of all-terrain adventures. New experiences will be easier to find too, thanks to the amazing on-board features and sophisticated control systems.
The Wolverine® RMAX™ 1000 family follows our development philosophy of "Jin-Ki Kanno" which translates from Japanese as "the exhilaration of being one with the machine" to bring you a super-capable off roader, in which driver and passengers feel confident to master the very toughest terrain.
COLOUR
Dusty Blue
AT A GLANCE
Specifications
| Bore x stroke | 93 mm x 73.5 mm |
|---|---|
| Compression Ratio | 11.2 : 1 |
| Displacement | 999cc |
| Drive system | On-Command® 2WD, 4WD, 4WD with Diff-lock and Turf mode |
| Engine Type | Liquid-cooled, 4-stroke, DOHC, Parallel Twin |
| Final transmission | Shaft |
| Fuel System | Mikuni fuel injection with dual 48mm throttle bodies |
| Ignition System | TCI |
| Lubrication System | Dry sump |
| Starter System | Electric |
| Transmission System | Yamaha Ultramatic® CVT automatic V-belt |
| Wet weight (including full oil and fuel tank) | 930 kg |
| Cargo bed | 272 kg |
|---|---|
| Fuel tank capacity | 35 L |
| Min. turning radius | 6,000 mm |
| Oil tank capacity | 5.5 L |
| Overall height | 2,110 mm |
| Overall length | 3,255 mm |
| Overall width | 1,677 mm |
| Seat height | 872 mm |
| Wheelbase | 2,290 mm |
| CAT_ORDER | 01 |
|---|---|
| ENQUIRY_AVAILABLE | YES |
| Manufacturer | Yamaha |
| Model | 2025 Wolverine® RMAX™4 1000 Compact LE |
| PARTEX_AVAILABLE | NO |
| TESTRIDE_AVAILABLE | NO |
| Type | Leisure |
| Front brake | Dual ventilated hydraulic disc |
|---|---|
| Front suspension system | Independent Double Wishbone with Anti-Sway Bar, 361 mm of wheel travel /FOX QS3 piggy back |
| Front tyres | AT29 x 9-14 GBC® Dirt Commander® |
| Rear brake | Dual ventilated hydraulic disc, Shaft mounted parking brake |
| Rear suspension system | Independent Double Wishbone with Anti-Sway Bar, 337 mm of wheel travel /FOX 2.0 iQS |
| Rear tyres | AT29 x 9-14 GBC® Dirt Commander® |
| Steering system | Rack and Pinion Steering Assembly with selectable Electric Power Steering |
| Towing capacity | 907 kg |
